'DLT 645-2007 采集程序


Public Function Cmd_DLT645(Address As Integer, Parameter As Integer)


Dim FrameSend(13) As Integer


'定义发送报文


FrameSend(0) = &HFE '帧起始符1
FrameSend(1) = &HFE '帧起始符2
FrameSend(2) = &H68 '帧长度
FrameSend(3) = &H8 + 6 '起始符
FrameSend(4) = &H11 '控制码
FrameSend(5) = 0 '系统地址高字节
FrameSend(6) = Address &HFF '系统地址低字
FrameSend(7) = 0 '功能码
FrameSend(8) = Parameter \ 256  '参数高字
FrameSend(9) = Parameter And &HFF '参数低字
FrameSend(10) = FrameSend(2) + FrameSend(3) + FrameSend(4) + FrameSend(5) + FrameSend(6) + FrameSend(7) + FrameSend(8) + FrameSend(9) '校验
FrameSend(11) = &H16 '结束符
FrameSend(12) = &HFE '帧尾符1
FrameSend(13) = &HFE '帧尾符2


'发送报文


SerialWrite FrameSend


End Function


'读取报文


Public Sub SerialRead()


Dim FrameRec(13) As Integer


SerialRead FrameRec


'校验帧起始符


If FrameRec(0) = &HFE And FrameRec(1) = &HFE Then


'校验结束符


If FrameRec(10) = &H16 And FrameRec(11) = &HFE And FrameRec(12) = &HFE Then


'校验报文长度


If FrameRec(2) = &H8 + FrameRec(3) Then


'校验校验码


Dim Crc As Integer


For i = 2 To 10


Crc = Crc + FrameRec(i)


Next


'校验码比较


If Crc = FrameRec(10) Then


'success


End If


End If


End If


End If


End Sub
